Model |
103GTH-PET |
|||
|
Material structure (Outside-to-inside) |
BOPET |
|||
|
ALOx |
||||
|
Coated layer |
||||
|
Printability/lamination (AlOx side) |
printable/ laminated |
|||
|
Retortability |
Not retortable |
|||
|
Hygienic standard |
Conform to FDA |
|||
|
Property |
Testing method |
Units |
Standard values |
|
|
Thickness |
GB/T 6672 |
µm |
12.5 |
|
|
Density |
ASTM D792 |
g/cm3 |
1.4 |
|
|
Yield |
/ |
g/㎡ |
17.3 |
|
|
Tensile Strength |
MD |
ASTM D882 |
MPa |
200 |
|
TD |
210 |
|||
|
Elongation |
MD |
ASTM D882 |
% |
200 |
|
TD |
200 |
|||
|
Haze |
ASTM D 1003 |
% |
2 |
|
|
Wetting Tension (AlOx side) |
ASTM D2578 |
dyne/cm |
48 |
|
|
Coefficient of Friction (uncoated side) |
ASTM D1894 |
/ |
0.55 |
|
|
OTR |
ASTM D 3985 (23℃，50%RH) |
ml/㎡.24h |
1.0 |
|
|
WVTR |
ASTM F1249 (38℃，90%RH) |
g/㎡.24h |
2 |
|
